Brilix 6-way valve TOP 1,5" for FSP 350, 450, 500, 650 filtration
Code: BXNDFN048
Related products
Product detailed description
| Dimensions | cm |
|---|---|
| Height without lever | 25.5 |
| Diameter of the part with seal (inner width of the filter vessel neck) | 14.5 |
| Inner diameter per tube | 5.0 |
| Diameter per clamp | 18 |
Pool Specialist Opinion - Review
- + Maximum compatibility with different filtration models
- Exact dimensions for a perfect fit
- Easy installation and maintenance
- High durability and long service life
- It does not come with a pressure gauge, but is ready to install
"The Brilix 6-way valve is a great step forward in pool filtration. Its versatile design and ease of installation make this valve an ideal choice for a range of filtration applications."
Team Poolservis
Universal valve for different types of filtration
Brilix 6-way valve is compatible with various filtration types, including FSP 350, 400, 450, 500 and 650 models, ensuring a wide range of applications.
Exact dimensions for a perfect fit
The valve has a diameter of 145mm with the seal section and a height of 255mm without the lever, ensuring a perfect fit in the filter vessel. The internal diameter for the pipe is 50mm and the diameter for the clamp is 180mm, making installation easy.
Easy installation and maintenance
Installation of this valve is straightforward and does not require complicated tools. Its design also facilitates routine maintenance and cleaning.
High durability and long service life
The valve is made of high-quality materials that guarantee its durability and long service life, which is essential for permanent use in swimming pool systems.
Practical outlets for different purposes
The valve is equipped with multiple outlets: a top outlet for suction of pool water, an outlet to the pool for water circulation, and an outlet to the channel for sand washing. In addition, it is equipped with a transparent slide for checking the washing, which is very practical for proper maintenance.
Manometer readiness
There is a pre-plugged outlet for a pressure gauge on the side of the valve, which can be purchased as required. This feature allows for better monitoring and control of system pressure.
Customer Satisfaction
According to customer feedback, the Brilix 6-way valve is highly rated for its reliability, durability and ease of installation.
Installation tips
It is important to follow the instructions carefully when installing this valve. Make sure that all connections are properly sealed and that the valve is firmly positioned. Regular inspection and maintenance will ensure its long-term functionality and reliability.
At the side of the valve is a plugged outlet for a manometer
Additional parameters
| Category: | Six-way valves |
|---|---|
| Weight: | 2 kg |
| Značka: | Brilix |
